Appendix
CONTROL CONTENTS COMMAND PARAMETER
RETURN
Power ON
Standby mode
(or 30-second startup time)
C.M.S. M-Hue (–30 — +30) C M H M _ * * * OK or ERR ERR
C.M.S. Hue Reset C M R E _ _ _ 2 OK or ERR ERR
C.M.S. R-Saturation (–30 — +30) C M S R _ * * * OK or ERR ERR
C.M.S. Y-Saturation (–30 — +30) C M S Y _ * * * OK or ERR ERR
C.M.S. G-Saturation (–30 — +30) C M S G _ * * * OK or ERR ERR
C.M.S. C-Saturation (–30 — +30) C M S C _ * * * OK or ERR ERR
C.M.S. B-Saturation (–30 — +30) C M S B _ * * * OK or ERR ERR
C.M.S. M-Saturation (–30 — +30) C M S M _ * * * OK or ERR ERR
C.M.S. Saturation Reset C M R E _ _ _ 3 OK or ERR ERR
C.M.S. R-Value (–30 — +30) C M V R _ * * * OK or ERR ERR
C.M.S. Y-Value (–30 — +30) C M V Y _ * * * OK or ERR ERR
C.M.S. G-Value (–30 — +30) C M V G _ * * * OK or ERR ERR
C.M.S. C-Value (–30 — +30) C M V C _ * * * OK or ERR ERR
C.M.S. B-Value (–30 — +30) C M V B _ * * * OK or ERR ERR
C.M.S. M-Value (–30 — +30) C M V M _ * * * OK or ERR ERR
C.M.S. Value Reset C M R E _ _ _ 4 OK or ERR ERR
C.M.S. All Reset C M R E _ _ _ 1 OK or ERR ERR
Clock (–150 — +150) I N C L * * * * OK or ERR ERR
Phase (–60 — +60) I N P H _ * * * OK or ERR ERR
H-Pos (–150 — +150) I A H P * * * * OK or ERR ERR
V-Pos (–60 — +60) I A V P _ * * * OK or ERR ERR
Fine Reset I A R E _ _ _ 1 OK or ERR ERR
RGB Horizontal Frequency Check T F R Q _ _ _ 1 OK or ERR ERR
RGB Vertical Frequency Check T F R Q _ _ _ 2 OK or ERR ERR
Auto Sync Off A A D J _ _ _ 0 OK or ERR ERR
Normal A A D J _ _ _ 1 OK or ERR ERR
High Speed A A D J _ _ _ 2 OK or ERR ERR
Image Shift (–30 — +30) S T S H _ * * * OK or ERR ERR
Subtitle (–30 — +30) S T S Z _ * * * OK or ERR ERR
Overscan (10% — 0%) *
2
O V S N _ * * * OK or ERR ERR
Options Reset O P R E _ _ _ 1 OK or ERR ERR
C1 White Level (–30 — +30) R A I G _ * * * OK or ERR ERR
C2 White Level (–30 — +30) R B I G _ * * * OK or ERR ERR
S-Video White Level (–30 — +30) V A I G _ * * * OK or ERR ERR
Video White Level (–30 — +30) V B I G _ * * * OK or ERR ERR
DVI White Level (–30 — +30) R C I G _ * * * OK or ERR ERR
C1 Black Level (–30 — +30) R A I O _ * * * OK or ERR ERR
C2 Black Level (–30 — +30) R B I O _ * * * OK or ERR ERR
S-Video Black Level (–30 — +30) V A I O _ * * * OK or ERR ERR
Video Black Level (–30 — +30) V B I O _ * * * OK or ERR ERR
DVI Black Level (–30 — +30) R C I O _ * * * OK or ERR ERR
LED Off L E D S _ _ _ 0 OK or ERR ERR
On L E D S _ _ _ 1 OK or ERR ERR
Lamp Usage Time (Hour) T L T T _ _ _ 1 0 - 9999(Integer)
Lamp Life (Percentage) T L T L _ _ _ 1 0% – 100% (Integer)
OSD Display Off I M D I _ _ _ 0 OK or ERR ERR
On I M D I _ _ _ 1 OK or ERR ERR
C1 INPUT Auto I A S I _ _ _ 0 OK or ERR ERR
Signal Type RGB I A S I _ _ _ 1 OK or ERR ERR
Component I A S I _ _ _ 2 OK or ERR ERR
C2 INPUT Auto I B S I _ _ _ 0 OK or ERR ERR
Signal Type RGB I B S I _ _ _ 1 OK or ERR ERR
Component I B S I _ _ _ 2 OK or ERR ERR
DVI INPUT D. PC RGB I C S I _ _ _ 3 OK or ERR ERR
Signal Type D. PC COMP. I C S I _ _ _ 4 OK or ERR ERR
D. VIDEO RGB I C S I _ _ _ 5 OK or ERR ERR
D. VIDEO COMP. I C S I _ _ _ 6 OK or ERR ERR
A. RGB I C S I _ _ _ 1 OK or ERR ERR
A. COMP. I C S I _ _ _ 2 OK or ERR ERR
H1 INPUT Auto I D S I _ _ _ 0 OK or ERR ERR
Signal Type RGB I D S I _ _ _ 1 OK or ERR ERR
YCbCr4:4:4 I D S I _ _ _ 7 OK or ERR ERR
YCbCr4:4:2 I D S I _ _ _ 8 OK or ERR ERR
H2 INPUT Auto I E S I _ _ _ 0 OK or ERR ERR
Signal Type RGB I E S I _ _ _ 1 OK or ERR ERR
YCbCr4:4:4 I E S I _ _ _ 7 OK or ERR ERR
YCbCr4:4:2 I E S I _ _ _ 8 OK or ERR ERR
H1 INPUT Auto H M D C _ _ _ 0 OK or ERR ERR
Color Space ITU601 H M D C _ _ _ 1 OK or ERR ERR
ITU709 H M D C _ _ _ 2 OK or ERR ERR
H2 INPUT Auto H M E C _ _ _ 0 OK or ERR ERR
Color Space ITU601 H M E C _ _ _ 1 OK or ERR ERR
ITU709 H M E C _ _ _ 2 OK or ERR ERR
DVI INPUT Auto H M C D _ _ _ 0 OK or ERR ERR
Dynamic Range Standard H M C D _ _ _ 1 OK or ERR ERR
Enhanced H M C D _ _ _ 2 OK or ERR ERR
H1 INPUT Auto H M D D _ _ _ 0 OK or ERR ERR
Dynamic Range Standard H M D D _ _ _ 1 OK or ERR ERR
Enhanced H M D D _ _ _ 2 OK or ERR ERR
H2 INPUT Auto H M E D _ _ _ 0 OK or ERR ERR
Dynamic Range Standard H M E D _ _ _ 1 OK or ERR ERR
Enhanced H M E D _ _ _ 2 OK or ERR ERR
Video System Auto M E S Y _ _ _ 1 OK or ERR ERR
PAL M E S Y _ _ _ 2 OK or ERR ERR
SECAM M E S Y _ _ _ 3 OK or ERR ERR
NTSC4.43 M E S Y _ _ _ 4 OK or ERR ERR
NTSC3.58 M E S Y _ _ _ 5 OK or ERR ERR
PAL-M M E S Y _ _ _ 6 OK or ERR ERR
PAL-N M E S Y _ _ _ 7 OK or ERR ERR
PAL-60 M E S Y _ _ _ 8 OK or ERR ERR
Background Logo I M B G _ _ _ 1 OK or ERR ERR
Blue I M B G _ _ _ 3 OK or ERR ERR
None I M B G _ _ _ 4 OK or ERR ERR
