- 8 -
EO1-11113
5.2. LOWER ROW (10-digit 7-segment Numeric Display)
AMOUNT (7 digits): Displays the numeric data, such as amount, quantity, etc.
When the amount is negative, the symbol "-" is displayed as well.
NOTE: When the following code is being entered, the digits for "RPT" and
"DPT" may be used as well (all 10 digits). On exceeding the 10 digits,
the lowest 10 digits are being displayed.
Non-add Number (max. 18 digits)
DPT (2 digits): Displays the Department Code of the department item just entered. The
department name is also displayed in the Upper Row. It stays lit when repeating
the same department item entry.
When a PLU is entered, PLU name is displayed in the Upper Row.
Program option allows an ECR to display either a cashier No. or Nos. of PLU price
shift and menu shift instead of a department code. In this case, department code
is not displayed even when department item is entered.
RPT (1 digit): Displays the repeat count of the same Department or PLU item. The count is
indicated from the second entry on, and only the lowest digit of the repeat count
will be displayed even when the count exceeds nine (such as "0" for 10, "1" for
11, etc.)
5.3. TRIANGULAR LAMPS
SIGN ON This lamp turns lit only when the Cashier Code Entry method is selected. It lights up
when a cashier has signed ON or signed IN. It goes out when the cashier has signed
OFF or signed OUT, and the message "LOG" is displayed in the Upper Row instead.
ALM Lights up with the alarm buzzer generated to indicate that the last operation or numeric
entry was an error. To clear the error status, depress the [C] key.
R OFF Lights up when the Receipt-OFF mode is declared by the [LOG/RECEIPT] (or
[RECEIPT]) key. In this condition, no receipts will be issued for a sale to be entered.
It goes out by depressing the [LOG/RECEIPT] (or [RECEIPT]) key again for Receipt-
ON mode.
TL Lights up on a finalizing operation with the total amount displayed when the sale is
finalized without any amount tendered.
ST Lights up when the [ST] key is depressed, indicating that the displayed amount is
subtotal. The lamp is also illuminated when the [TXBL TL] or [FSTL/TEND] key is
depressed, indicating that the displayed amount is the taxable total or food-stampable
total. It also lights up when the amount tendered is less than the sale total with the
shortage amount (balance due) is displayed.
CG When an amount tendering operation is performed, it lights up with the change due
displayed.
5.4. STATUS LAMPS
SLIP Lights up when a validation slip is properly inserted to allow validation print. It flickers
to require a validation when the validation compulsory status has been programmed
on the last operation. It also flickers to require an endorsement print using the Guest
Check Printer or the Receipt/Journal Printer.
IN-LINE It is used when the ECR is used as an terminal in a Master-Satellite system. When the
ECR is used as a stand-alone machine, this lamp is not used.
