Prestige 645R-A Series User’s Guide
IP Policy Routing 21-5
Table 21-2 Menu 25.1.1 IP Routing Policy
FIELD DESCRIPTION
Len Comp
Press [SPACE BAR] and then [ENTER] to choose from Equal, Not Equal,
Less, Greater, Less or Equal or Greater or Equal.
Source:
addr start / end Source IP address range from start to end.
port start / end Source port number range from start to end; applicable only for TCP/UDP.
Destination:
addr start / end Destination IP address range from start to end.
port start / end Destination port number range from start to end; applicable only for TCP/UDP.
Action
Specifies whether action should be taken on criteria Matched or Not
Matched.
Gateway addr Defines the outgoing gateway address. The gateway must be on the same
subnet as the Prestige if it is on the LAN, otherwise, the gateway must be the
IP address of a remote node. The default gateway is specified as 0.0.0.0.
Type of Service Set the new TOS value of the outgoing packet. Prioritize incoming network
traffic by choosing No Change, Normal, Min Delay, Max Thruput, Max
Reliable or Min Cost.
Precedence
Set the new outgoing packet precedence value. Values are 0 to 7 or No
Change.
Log
Press [SPACE BAR] and then [ENTER] to select Yes to make an entry in the
system log when a policy is executed.
When you have completed this menu, press [ENTER] at the prompt “Press ENTER to confirm or ESC to
cancel” to save your configuration or press [ESC] to cancel and go back to the previous screen.
21.5 Applying an IP Policy
This section shows you where to apply the IP policies after you design them.
21.5.1 Ethernet IP Policies
From Menu 3 — Ethernet Setup, type 2 to go to Menu 3.2 — TCP/IP and DHCP Ethernet Setup.
You can choose up to four IP policy sets (from 12) by typing their numbers separated by commas, for
example, 2, 4, 7, 9.
