PLB-CF10
Cardframe with 10 Card Slots and 16 Port Hub
FG993
FEATURES
• Holds up to 10 control cards
• Acts as system master with Master Control Card
• Operates interactively over high-speed Ethernet connection to system PC with
PHAST software and PLC-MCU Card
• Distributes PHASTLink from 15-port PHASTLink data hub
CARD SLOTS
• 10 rear-access slots
HUB LINK
• 2 RJ-45 ports to hubs and Cardframes
PHASTLINK
• 15 RJ-45 PHASTLink ports
DIP SWITCH
• Sets Cardframe device number
DIMENSIONS (HWD): 5.56" x 17.13" x 15.25"
(141.2 mm x 435.1 mm x 387.4 mm)
WEIGHT: 19.8 lbs (9.0 kg) (w/o cards)
POWER: 110/220 VAC, 50/60 Hz, 100 mA (w/o cards)
ACCESSORIES
• PM-RAC Rack-Mount Kit, requires 3 rack spaces (5.25")
PLB-CF2
Cardframe with 2 Slots
FG718
FEATURES
• Holds up to two control cards
• Acts as system master (with MCU card) or adds two control cards to an
existing system
• Operates interactively over high-speed Ethernet connection to system PC
with PHAST software (with MCU card)
• Distributes control from PHASTLink ports, supports up to 10 devices and
one keypad in Master mode
CARD SLOTS
• Two rear-access slots
PHASTLINK
• Two RJ-45 ports
DIP SWITCH
• Sets Cardframe device number
LED INDICATORS:
• Red Link LED on front
• Red Power LED on front
• Green Data LED on back
• Red DIAG (diagnostic) LED on back
DIMENSIONS (HWD): 2.0" x 6.3" x 13.5" (50 mm x 159 mm x 336 mm)
WEIGHT: 3.5 lbs (1.6 kg) w/o card
POWER: 40 mA w/o cards, 1.5 A 12 VDC power supply included
ACCESSORIES
• PM-RAC2 PLB-CF2 Rack-Mount Kit (holds 2)
PLC-MCU4
4MB Master Control Card
FG754
APPLICATION
• Master system processing and memory one required per system
PHASTLAN
• RJ-45 Ethernet 10baseT port to system PC
MEMORY
• 4MB Flash
• 4MB SRAM
POWER: 480 mA
PLC-AMX
AMX Emulation Card
FG0751
APPLICATION
• Link up to 255 Axcess devices
AXLINK
• 4-pin AXLink data/power bus
PROGRAM
• 9-pin male D-Sub programming connector
POWER
• 130 mA (card itself, additional power may be needed for devices)
PLC-IN7
7-Contact Input Card
FG0741
APPLICATION
• Sense closures or TTL voltage changes
INPUTS
• 1-7: 7 inputs, closure or 0–5 VDC voltage change
POWER
• +12 and +5 VDC power for accessories, 1 A max
WIRING
• 16-pin screw terminal
POWER
• 25 mA (May need additional power to operate connected devices)
PLC-IRIN
IR Input Card
FG0729
APPLICATION
• Accepts Landmark IR commands from up to 3 sensors
IR IN 1–3
• Three inputs for industry-standard IR sensors
WIRING
• Three 3-pin screw terminals for sensor data and power
POWER
• 45 mA
LANDMARK
LANDMARK CARDFRAMES
LANDMARK MASTER CARDS
LANDMARK CONTROL CARDS
