VIEWPOINT TOUCH PANELS
Designed for flexible wireless operation, 1-way ViewPoint panels communicate
with Axcess receivers via 1-way RF or IR commands. A plug-in high-power,
rechargeable NiMH Battery Pack delivers up to two weeks of power with typical
use, or up to six hours of continuous operation.
DISPLAY TYPE:
• 256-color passive-matrix LCD
SCREEN DIMENSIONS:
• 6" (152 mm) diagonal; 4.7" x 3.5" (118 mm x 89 mm)
SCREEN RESOLUTION (HV):
• 320x240 pixels
MEMORY:
• 2.5MB (2MB flash)
TRANSMISSION:
• 1-Way Wireless RF – Must specify frequency
• 1-Way Wireless IR – Switchable high-/low-frequency IR (455 or 38 kHz). Can
transmit downloaded manufacturer IR codes
INCLUDES: (DOES NOT INCLUDE RECEIVER)
• Four programmable side-screen control buttons
• Internal battery charger
• VPA-BP rechargeable NiMH battery
• 1.5 A @12 VDC power supply
• 3´ (9.8 m) RS-232 programming adapter cable
ENCLOSURE:
• Molded plastic with black matte finish
DIMENSIONS (HWD):
• 2.8" x 8.8" x 6.0" (71 mm x 222 mm x 152 mm)
POWER:
• Power supply or battery (6-hour continuous battery operation)
WEIGHT:
• 1.8 lbs (0.8 kg) with battery
• 1.6 lbs (0.7 kg) without battery
SOFTWARE:
• TPDesign3 Touch Panel design/programming
• VPXpress ViewPoint System Software
OPTIONS:
• VPA-DS ViewPort Docking Station
• VPA-BP Battery Pack
• AXR-RF Receiver
Wireless ViewPoint Touch Panels are an elegant integration of graphic control, wireless convenience, timeless styling and low-cost
practicality. The 1-way and 2-way ViewPoint panels are designed for both desktop and hand-held operation.
VPN-CP
2-Way ViewPoint Color Wireless
Touch Panel
(includes VPA-BP battery)
FG5964-02 2.4 GHz, Black
VPT-CP
1-Way ViewPoint Color Wireless Touch panel
FG5964-304 304 MHz, Black
FG5964-418 418 MHz, Black
FG5964-433 433 MHz, Black
FG5964-310 310 MHz, Black
FG5964-315 315 MHz, Black
Designed for flexible wireless operation, 2-way ViewPoint panels communicate
with Axcess receivers via 2-way NetWave RF, a new spread-spectrum
technology that delivers increased performance and range. A plug-in high-
power, rechargeable NiMH Battery Pack delivers up to two weeks of power with
typical use, or up to six hours of continuous operation.
DISPLAY TYPE:
• 256-color passive-matrix LCD
SCREEN DIMENSIONS:
• 6" (152 mm) diagonal; 4.7" x 3.5" (118 mm x 89 mm)
SCREEN RESOLUTION (HV):
• 320x240 pixels
MEMORY:
• 2.5MB (2MB flash)
TRANSMISSION:
• 2-Way NetWave RF – 2.4 GHz spread-spectrum 500-foot range
• 1-Way IR – Can transmit downloaded manufacturer IR codes
INCLUDES: (DOES NOT INCLUDE RECEIVER)
• Four programmable side-screen control buttons
• Internal battery charger
• VPA-BP rechargeable NiMH battery
• 1.5 A @12 VDC power supply
• 3' (9.8 m) RS-232 programming adapter cable
ENCLOSURE:
• Molded plastic with black matte finish
DIMENSIONS (HWD):
• 2.8" x 8.8" x 6.0" (71 mm x 222 mm x 152 mm)
POWER:
• Power supply or battery (6-hour continuous battery operation)
WEIGHT:
• 1.8 lbs (0.8 kg) with battery or 1.6 lbs (0.7 kg) without battery
SOFTWARE:
• TPDesign3 Touch Panel design/programming
• VPXpress ViewPoint System Software
OPTIONS:
• VPA-DS ViewPort Docking Station
• VPA-BP Battery Pack
• AXR-NWS NetWave Server
*LIMITED AVAILABILITY*
*LIMITED AVAILABILITY*
