Holding up to three Axcess control cards, the Axcess Mini-CardFrame fits
between full CardFrames and Bus Controllers. For example, a system may need
a unique combination of control cards located close to a remote camera
pan/tilt/lens head. In another, the Mini-CardFrame could add three volume
cards to an AXCENT2 system. A distributed system may use the unit for IR,
relay and volume control in small meeting rooms. Each Mini-CardFrame adds
three control ports to the Central Controller, up to 255 devices. To use as a
small, stand-alone Central Controller, add an optional AXC-EM Enhanced
System Master Card to the Master slot.
CONTROL PORTS
• Three front-access control card slots
• Three rear-mounted control cable jacks (16-pin)
INCLUDES
• Integrated AXC-S Server Card to manage CardFrame communication
• One AXLink port
ENCLOSURE: Wall- or rack-mount metal with black matte finish
DIMENSIONS (HWD): 1.75" x 17.0" x 13.64"
(44.5 mm x 431.8 mm x 346.5 mm)
WEIGHT: 5.5 lbs (2.5 kg)
OPTIONS
• AXC-EM Enhanced System Master Card
• CSB Cable Support Bracket
The AXB-MPE+ Master Port Expander drives 12 independent AXLink wiring
runs of up to 3,000 feet each. The Master Port Expander also includes the
AXC-EM Enhanced Master Card for automatic backup processing.
CONTROL PORTS
• 12 independent AXLink bus connections
• Data In and Out RJ-11 ports for daisy-chain operation
INCLUDES
• AXC-EM Enhanced Master Card
• Front-panel setup switches and status LEDs
ENCLOSURE: Rack-Mount, metal with black matte finish
DIMENSIONS (HWD): 1.72" x 19" x 12.5"
(43.6 mm x 482.6 mm x 317.5 mm)
WEIGHT: 6 lbs (2.7 kg)
OPTIONS
• Backup AXC-EM, placed inside AXB-MPE+
The AXB-SPE Server Port Expander drives 12 independent AXLink wiring runs
of up to 3,000 feet each. The Server Port Expander operates from an SPE
connection with the AXB-MPE+ Master Port Expander or NXC-ME260 NetLinx
Master260 Card.
CONTROL PORTS
• 12 independent AXLink bus connections
• Data In and Out RJ-11 ports for daisy-chain operation
INCLUDES
• Front-panel setup switches and status LEDs
ENCLOSURE: Rack-Mount, metal with black matte finish
DIMENSIONS (HWD): 1.72" x 19.0" x 12.5"
(43.6 mm x 482.6 mm x 317.5 mm)
WEIGHT: 6.0 lbs (2.7 kg)
AXF-MINI
Mini-CardFrame (up to 3 AXC control cards)
FG731
AXB-SPE
Server Port Expander (requires AXB-MPE & AXB-MPE+)
FG714
AXB-MPE+
Master Port Expander (with AXC-EM card)
FG713-10
AXCESS CARDFRAMES
