AXIS 5600 User’s Manual Section 9: Management & Configuration
127
The Serial Printer Port
HP JetAdmin does not support serial printer ports. If you must change
the default settings of the serial printer port of the AXIS 5600, it is
recommended that you use the AXIS NetPilot. This will become
necessary when you are installing a printer on your serial port. Follow
the steps below to change the serial port parameters using AXIS
NetPilot.
1. Start the AXIS NetPilot.
2. Select your AXIS 5600 and click Install on the AXIS NetPilot
toolbar. Select with current configuration.
3. Your AXIS 5600 has been transferred to the ‘Network Print
Servers’ folder. Select your AXIS 5600 and click the Property
button on the AXIS NetPilot toolbar.
4. Select the Printer Ports tab.
5. Select COM1 from the Printer Port drop-down list.
6. Select XON/XOFF from the Handshake Protocol drop-down list,
set the Baud Rate to 38400 and select 1 stop bit. Click OK.
The settings in step 6 varies between different printer models. Please
refer to your printer documentation.
If your network supports TCP/IP you can also change the serial port
parameters by using the AXIS 5600 Web interface.
