Chapter 1 Specifications
1-2. Printable Area
1-9 CL-S700/CL-S703/CL-S700R
1-2. Printable Area
The printable area of the printer is as follows:
When media is set to the printer, it must be aligned with the media guide at the left of the printing
mechanism. Though the available maximum media width is 118 mm (4.65"), there are unprintable
areas on both sides: 2.5 mm (0.10") width is on the left side and 11.5 mm (0.45") (for CL-S700/
CL-S700R)/10.5 mm (0.41”) (for CL-S703) width on the right side.
The left side unprintable area applies for any size media.
MODEL H R
CL-S700/CL-S700R
104.0 mm
(4.1”)
11.5 mm
(0.45”)
CL-S703
105.0 mm
(4.1”)
10.5 mm
(0.41”)
Maximum media width: 118 mm (4.65")
H
R
Reference end
Unprintable area
Printable area
Media guide
Direction of media feed
2.5 mm (0.10")
