A.2 Locations of Connectors and Setting Terminals (MP model)
(Bottom view)
(Rear view)
Figure A.2 Locations of connectors and setting terminals (MP model)
CN1
CN2
Pin 34
Pin1
Pin A11 Pin A1
Pin 1
Pin 68
Pin 35
Pin A12 Pin A2
SCSI connector (CN1) Connector for external operator panel (CN1)
Power connector (CN1)
