BASE UNIT: Supports 24 ports of communication at up to 5.5M
bps total throughput speeds.
I/O Modules: Four ports per module. Maximum 6 modules
per unit. Must have a minimum of 4 serial ports per unit.
Maximum Input Power Rating: 115 VAC, 50/60 Hz, .3A;
Opt 230 VAC, 50/60 Hz, .2A
Power Supply: +5VDC, 1.5A; +12VDC, 0.2A; -12VDC,
0.2A available.
Power Requirement: 115 VAC, 50/60 Hz, .3A; Optional 230
VAC, 50/60 Hz, .2A.
Single Channel Bus Speed: 5.5M bps.
Configuration memory: 8KB non-volatile memory holds
power-up default information.
Expansion slots: 6 external; 2 internal.
Edge connecters:20 pin; 6 total, one for each external
expansion slot.
26-Pin headers: Two for installation of internal memory or
internal modem modules.
Environment: 0 to 55 C temperature; 5% to 95% humidity.
Dimensions: 16¾"w x 10"d x 3½"h.
Weight: 9½ lbs. with 6 modules installed; 8 lbs. with no I/O
modules installed.
Indicators: 1 green power LED; 24 red port activity LEDs.
Mounting: Desk-top; rack-mount optional.
Warranty: One year on parts and labor.
MEMORY BOARD: 1 board standard - no memory installed.
Expandable to 16MB by one megabyte or four megabyte
increments.
