OPTION ACCESSIBILITY: Through Port 1 of Module 1 only.
By responding to the Enter Request: message at the end of the main
configuration menu (see
Section 8.1
) with "4" (Program Port Select
Code), you may change the Port Select Code to a user-defined code.
This Port Select Code consists of any ASCII character string (1 to 8
characters).
The Model 24SII DES will respond with the following:
Enter Request :4
Port Select Code is: $SELECT
Enter Port Select Code (Max. 8 characters)
or ENTER for no change :
Enter the new Port Select Code. If less than 8 characters are entered,
you must follow entry by striking the Enter key.
NOTE: Non-printable characters are acceptable, but they will not
appear in the Status menu.
For example, if you entered #PORT, the Model 24SII DES will
respond with:
Port Select Code is: #PORT
Enter Port Select Code (Max. 8 characters)
or ENTER for no change :
If no additional change is desired, strike the Enter key to exit.
The Model 24SII DES will save the new Port Select Code
permanently in non-volatile memory and will subsequently power-up
with that code in effect.
The Model 24SII DES will now return to the main configuration menu
(see
Section 8.1
).
