Model 24SII DES CONFIGURATION GUIDE
Menu Options Factory
Default
User Options Notes
Word Size: 8
Stop Bits: 1
Parity: none
XON/XOFF
Xmit: off
XON/XOFF
Recv: off
Printer
Sharing Mode:
bidirectional
4-Wire/8-Wire
Operation: 8-
wire
460.8k
Word Size: 7 or 8 bits
Stop Bits: 1 or 2
Parity: even, odd, none
XON/XOFF: enabled or
disabled individually for
transmit and receive
Printer Sharing Mode may
be unidirectional or
bidirectional
4-Wire/8-Wire Operation
may be set to 4-wire or 8-
wire
different serial protocols
and will do serial/parallel
conversions.
XON/XOFF for Xmit should
always be set to OFF
when sending graphics or
binary data.
Programmable for high
speed serial modules only.
Max baud rate using
bidirectional is 115.2K bps,
max baud rate using
unidirectional is 460.8K
bps.
Programmable for the
M24SII-V07 high speed
module only.
Set Input
Inactivity
Timeout
20 seconds 0 to 200 seconds A long timeout setting for a
PC will prevent other PCs
from accessing the port it
is connected to, while
allowing the connected PC
to send numerous print
jobs. If you do not want to
wait a long time between
various users print jobs, it
is suggested that you send
a disconnect code at the
end of the print job to
override the timeout.
A longer timeout may be
required when sending
large text files, graphics
files, or downloading fonts.
A zero will disable the
Input Inactivity Timeout
and the end of a print job
will occur only when codes
are manually entered and
sent from the connected
PC.
WARNING: Do not set
timeout to zero seconds
when Port Select Mode B
