PRINTER PORTS
NOTE: Printer ports using this configuration will support hardware
handshaking only. You must ensure hardware handshaking is
supported by the equipment that will connect to these ports.
Printer ports on the M24SII-V07 module using EIA-232 Protocol, 4-
wire Operation, and unidirectional Printer Sharing Mode utilize the
following pins and signals for communication:
RJ-11 PIN-OUT INFORMATION
PIN SIGNAL
EIA-232
DIRECTION DESCRIPTION
1 NC ---- No connection
2 TX Output Transmit Data
3 CTS Input Handshake In,
enable/disable the
transmission of characters
4 GND ---- Signal Ground
If you are connecting a device to a printer port on the M24SII-V07
module using EIA-232 Protocol, 4-wire Operation, and unidirectional
Printer Sharing Mode, please see
Appendix A.7.3
for adapter pinouts
and recommended cabling.
