FACTORY POWER-UP DEFAULT CONFIGURATIONS:
Serial ports:
Baud rate: 9600.
Word size: 8 bits.
Parity: None.
XON/XOFF: Off.
Printer sharing mode (high speed serial modules
only): Bidirectional.
4-Wire/8-Wire Operation (M24SII-V07 high speed
serial module only): 8-wire.
Logical Name: Device A to D on each module.
Input Inactivity Timeout: 20 seconds.
Port Designation: Port 2 of Module 1- printer port; all other
ports - computer ports.
Default Printer Assignment: 0 for all computer ports
(contention mode).
Port Select Code: $SELECT.
Printer Select Mode: Anytime.
Form Feed Mode: Disabled.
I.D. Page Message: "This print job is for:".
I.D. Page Message Schedule: Before each print job.
I.D. Page Message Enable: Off.
Minimum Size Print Job: 3 characters.
USER-PROGRAMMABLE CONFIGURATIONS:
Easy to configure using on-screen menu. Choices are saved in
non-volatile memory to become the new power-up default
configuration.
Configurable Through any Serial Computer Port:
Baud rate for bidirectional transfer (high speed serial
modules only)*: 300, 600, 1200, 2400, 4800, 9600,
19200, 38400, 115.2k.
Baud rate for unidirectional transfer (high speed serial
modules only)*: 9600, 115.2k, 230.4k, 460.8k.
* Option configurable per port.
