C650 3-43
Administrator mode
3
3.5 Store Address tab
On the Store Address tab, transmission settings and information and settings concerning the destinations
are displayed.
!
Detail
For details on the following menu items, refer to "Store Address tab" on page 2-23.
Address Book, Group, Program, Temporary One-Touch, Subject, and Text
Application Registration
!
Detail
"Application Registration" appears in the menu only if the following two conditions are met.
• The optional fax kit is not installed.
• Internet faxing is disabled.
When using an application, such as RightFax Server, registered with an external server, register the
application information and server address. By registering the application and server, a connection to the
server of the selected application can automatically be established for use.
Operations that can be performed by registering applications
Up to five applications and servers can be registered. Depending on the settings of the registered application,
settings for custom items can be specified. PageScope Web Connection provides templates for the
following. Different custom items are specified in advance with the template, depending on the application.
2
Note
If templates are not used, specify the settings for custom items manually.
2
Reminder
Registered applications can be displayed and used from the control panel of the machine only if the
following two conditions are met.
• The optional fax kit is not installed.
• Internet faxing is disabled.
If "WalkUp Fax" is selected
If "Fax with Account" is selected
No. Button Name Function Name Keyboard
Type
Default Val-
ue
Options
1 Sender Name (CS) Name ASCII Walkup -
2 Fax Number (CS) PersonalFaxNumber ASCII - -
3 TEL Number (CS) PersonalVoiceNumber ASCII - -
4 Subject Subject ASCII - -
5 Billing Code 1 BillingCode1 ASCII - -
6 Billing Code 2 BillingCode2 ASCII - -
No. Button Name Function Name Keyboard
Type
Default Val-
ue
Options
1 Sender Name (CS) Name ASCII - -
2 User ID ID ASCII Walkup -
3 Password Password ASCII - -
4 Password Auth# Authentication - - None
5 Subject Subject ASCII - -
6 Billing Code 1 BillingCode1 ASCII - -
