C650 3-54
Administrator mode
3
2
Reminder
In order to apply the changes to the settings for items which are marked with an asterisk (*), restart the
machine (turn it off, then on again).
When the machine is turned off, then on again, turn the machine off with the [Power] (auxiliary power)
key before turning off the main power switch. In addition, wait at least 10 seconds to turn the machine
on after turning it off; otherwise, the machine may not operate correctly.
When using this machine under the IPv6 environment, there are the following restrictions.
- Printing using SMB is not available (available for direct hosting service).
- Sending scan data using SMB is not available (available for direct hosting service).
- SMB browsing is not available.
- PageScope NDPS Gateway cannot be used.
- DHCPv6 cannot be used.
- IP filtering is not available.
- The printer driver installer cannot be used.
- PageScope Web Connection cannot be displayed with Flash.
To specify a destination computer using the computer name in the IPv6 environment, the Direct Hosting
setting must be enabled. To enable the Direct Hosting setting, prepare a DNS server and be sure to specify
the DNS settings of this machine correctly. For details on specifying direct hosting settings, refer to "SMB
Setting - Direct Hosting Setting" on page 3-70.
Item Description
TCP/IP
*
Select whether or not TCP/IP is used.
Network Speed Select the operating speed.
IP Address Setting Method* Select whether the IP address is automatically acquired or is directly entered. If it is
automatically acquired, select the check boxes to specify the acquisition condi-
tions.
IP Address Specify the IP address of the machine. (Format: ***.***.***.***; Range for ***: 0 to 255)
Subnet Mask Specify the subnet mask of the connected network. (Format: ***.***.***.***; Range for
***: 0 to 255)
Default Gateway Specify the default gateway for the connected network. (Format: ***.***.***.***;
Range for ***: 0 to 255)
IPv6 Select whether or not IPv6 is used.
If "ON" is selected, specify settings for the following.
• Auto IPv6 Setting
*
• Global Address
• Prefix Length
• Gateway Address
RAW Port Number Select the check box for the port to be used, and then type in the port number.
(Range: 1 to 65535)
Dynamic DNS Setting Select whether or not Dynamic DNS is enabled.
Host Name If Dynamic DNS is enabled, type in the host name (up to 63 characters).
DNS Domain Name Setting Select whether or not the DNS domain name is automatically acquired. If it is not
automatically acquired, type in the domain name below (up to 253 characters).
DNS Server Setting A maximum of three DNS server addresses can be registered. (Format: ***.***.***.***:
Range for ***: 0 to 255)
If the machine is set to use IPv6, an IPv6 address can also be specified.
SLP Setting Select whether or not SLP is enabled.
LPD Setting Select whether or not LPD is enabled.
