C650 2-28
User mode
2
If "Internet Fax" was selected
2
Note
"Internet Fax" appears if the Internet fax operation is available.
Address Book - Icon
The list of destinations currently registered in the address book can be displayed, and destination icons can
be registered or changed.
2
Note
The icons are used in the image panel function which can be operated when the optional i-Option LK-
101 or LK-103 is installed.
For details on the available settings, refer to "Address Book - Store Address" on page 2-23.
Item Description
No. Specify the registration number.
Select "Use opening number" or "Direct Input". If "Direct Input" is selected, type in
the number. If "0" is specified, the user box is automatically registered with the next
available number.
Name Type in the name of the destination (up to 24 characters).
Index Select the index characters for the destination. To normally display the destination
in the touch panel, check the "Main" check box.
E-Mail Address Type in the address of the destination (up to 320 characters).
Resolution Select the resolution.
Paper Size Select the paper size.
Compression Type Select the compression method.
Limiting Access to Destinations To specify the access level of the destination, click the [Display] button. If an access
permission group is specified for the user who is logged on, the settings for "Search
from Reference Allowed Group" appear.
If "Search from Reference Allowed Group" is selected, click the [Search from List]
button, and then select an access permission group from the list. If "Set direct Ref-
erence Allowed Level" is selected, select a level.
