Duplexing Paper Labels
17
P/N 56P2109. This wiper makes it possible to print on both sides of paper labels specifically
designed for duplexing. In addition, you can use this wiper to simplex paper labels and duplex paper
in the same printer. When ordering a new cartridge, be sure to order the cartridge that includes the
correct fuser wiper.
Figure 1. Optra S Rib Locations
(rib width = 2mm)
Figure 2. Optra T and Lexmark T Rib Locations
(rib width = 2mm)
20 mm
21 mm
27 mm
22 mm
15.5 mm
21.5 mm
28 mm
26 mm
17 mm
15 mm
Reference
Plate
16 mm
11 mm
15 mm
13 mm
16 mm
17 mm
26 mm
18 mm
12 mm
20 mm
15 mm
12 mm
4.02 mm
Reference
Plate
