Installing a memory card
29
Installing and removing options
Installing a memory card
Complete the following instructions to install a printer memory card.
Note: Memory cards designed for other Lexmark printers may not work with your printer.
1 Remove the system board access cover. (See Removing the system board access cover.)
2 Push open the latches on both ends of the memory card connector.
3 Unpack the memory card.
Warning: Printer memory cards are easily damaged by static electricity. Touch something metal such as the
printer frame before you touch a memory card.
Avoid touching the connection points along the edge of the card. Save the packaging.
4 Align the notches on the bottom of the card with the notches on the connector.
5 Push the memory card firmly into the connector until the latches on either end of the connector snap into place.
It may require some force to fully seat the card.
6 Make sure each latch fits over the notch on the end of the card.
Installing a flash memory or firmware card
Note: Flash memory and firmware cards designed for other Lexmark printers may not work with your printer.
1 Remove the system board access cover (see Removing the system board access cover).
Warning: Flash memory and firmware cards are easily damaged by static electricity. Touch something metal,
such as the printer frame, before you touch a card.
2 Unpack the flash memory or firmware card.
Avoid touching the metal pins on the bottom of the card. Save the packaging.
Notches
