OWNER’S HANDBOOK
5/10 Connecting optional devices
Connecting a serial port device
You can connect a device such as a modem or barcode
scanner to the serial port of the Multimedia Pack.
Note
When disconnecting the serial device, turn off the device
before you shut down the Pedion.
To connect a serial device
1.
Shut down the Pedion.
2.
Plug the serial cable into the serial port on the
rear of the Multimedia Pack. Tighten both the
screws to secure the connection.
3.
Connect the serial cable to the device as
described in the device’s manual.
4.
Turn on the serial device (if applicable).
5.
Turn on the Pedion.
