Hardware Setup
17
D6300 WiFi DSL Modem Router
Side Panel
The WiFi modem router side panel has the port and buttons shown in the figure.
Wireless On/Off button
WPS On/Off button
USB port
Figure 5. Side panel buttons and port
The following tables describe the buttons and port on the side panel from top to bottom.
Table 6. Wireless button
Icon Description
For information about the use of this button, see Wireless Connectivity on page 127.
Table 7. WPS button
Icon Description
For information about the use of this button, see Wi-Fi Protected Setup (WPS) Method on
page 27.
