44
Model No. CF-25LJF8EAM/E CF-25LGF8EAM CF-25LGC4EAM/E
CPU Pentium
®
Processor with MMX
TM
technology 166 MHz
Cache Memory (second cache memory) 32 KB (256 KB)
EDO Memory (Expandable to) 32MB (96 MB Max. ) 16 MB(80 MB Max.)
Video Memory 1.1 MB
LCD Type 12.1" (TFT) 10.4" (TFT)
Displayed Colors 256/65536/262144 colors(640 x 480 dots) / 256/65536 colors(800 x 600 dots)*
Hard Disk Drive (including about 110 MB used 2.1GB** 1.44GB**
specifically by the system)
Keyboard Windows 95 keyboard (for U.S.A.: 87 keys, for U.K.: 89 keys)
Floppy Disk Drive 720 KB/1.44 MB (two-mode)
PC Card Slots Three Type I or Type II, or one Type III + Type I or Type II
CardBus(middle or bottom slot) / ZV Port (bottom slot) Compatible
Slots (Confirmation with the dealer required beforehand) page 23
Allowable current 3.3 V: 400 mA, 5 V: 400 mA,
(total for three slots) 12 V: 120 mA
RAM Module Slot 144-pin, 3.3-V, SO-DIMM page 24
Multimedia Pocket One slot (for floppy disk drive, CD-ROM Pack, Second Battery Pack)
Parallel Port Dsub 25 pin female
Ext. Display Port Mini Dsub 15 pin female
Serial Port Dsub 9 pin male
Interface Headphone Jack Miniature jack, 3.5 DIA
Impedance 32 Ω, Output Power 4 mW (Impedance 32 Ω) x 2
Infrared Communication Port IrDA compliant, 115,200 bps data transmission speed
Ext. Keyboard/Mouse Port Mini DIN 6-pin female
Expansion Bus Connector Dedicated 80-pin female
Speaker Mono Speaker (built in)
Sound 16 bits, 44.1 kHz PCM/FM sound (Sound Blaster PRO Compatible)
Software Operating System Microsoft
®
Windows
®
95 (FAT32 File System)
Utility Programs Diagnostics program, TranXit program, PhoenixCard Manager95
Battery Pack Lithium Ion 10.8 V, 2300 mAh
Operating Time Approx. 1.5- 4 hours*
Battery Charging Time Power On Approx. 3.5 hours*
Power Off Approx. 2 hours*
Clock Battery Coin type lithium battery 3.0 V
Operating Time Approx. 10 years
Pointing Device Touch Pad (Pointing device adapting capacitance sensing method)
AC Adapter Input 100 -240 V AC, 50 / 60 Hz Output 15.0 V DC, 2.6 A
Power Consumption Approx. 38 W** (maximum when recharging in the ON state)
Physical Dimensions (W X H X D) 299 mm X 59 mm X 237 mm (11.8" X 2.3" X 9.3")
Weight Approx. 3.4 kg (Approx. 7.5 lbs) (With the floppy disk drive installed)+handle 0.2 kg (0.4 lbs)
Main Specifications
Specifications
* 800 x 600 16-color resolution is not supported. If this resolution is selected, the message
"There is an error in the display settings" will appear when you reboot. Start up again,
selecting 256 colors or high color (16 bits), following the instructions on the screen.
Besides this phenomenon, you might encounter some unexpected behavior. Do not select
16 color mode in any resolution.
** 1GB = 10
9
bytes
Other Specifications
* Varies depending on the usage conditions.
** Approx. 1.1 W when the battery pack is fully charged (or not being charged) and the computer is OFF.
