Control Codes PcOS Series 150 Programmer's Guide
EPOS Deviations
Page 72 Rev G 12/14/99
Function Set print direction
ASCII [ESC] T <n>
Description The Series 150 Printer does not implement page mode. This command
uses the normal rotated print format procedures. See [ESC] r <n> in
normal mode.
Note: EPOS reverses Modes 1 and 3.
Function Print graphics
ASCII [ESC] * <m> <n>
1
<n>
2
Description The Series 150 Printer defines the extended graphic modes. Mode 4 is
normally 80 dpi. The Series 150 Printer does not support 80 dpi. If
Mode 4 is selected, 72 dpi will be used.
Print n1 + 256 * n2 bytes of graphics where m specifies the density.
Where m 0 Single-density graphics 60 dpi
1 Double-density graphics 120 dpi
2 Double-density half-speed graphics 120 dpi
3 High-density graphics 240 dpi
4, 5 CRT II screen 72 dpi
6 CRT I screen 90 dpi
7 Dual plotter 144 dpi
Function Turn 90°° clockwise font ON/OFF
ASCII [ESC] V <n>
Description The Series 150 Printer uses the rotated 90° font to implement this
command. If one dot spacing is selected, ten cpi is used. If 1.5 dot
spacing is selected, eight cpi is used.
Function Select print paper
ASCII [ESC] c 0 <n>
Description The Series 150 Printer uses this command to select a print station. The
Series 150 Printer does not keep track of different settings for each
mode. If a specific print mode is required, it must be respecified.
Function Select print paper for setting
ASCII [ESC] c 1 <n>
Description The Series 150 Printer does not keep track of different settings for
each mode. If a specific print mode is required, it must be respecified.
Function Select detectors to stop printing
ASCII [ESC] c 4 <n>
Description The Series 150 Printer does not stop at the end of forms. The
application must keep track of the form length.
