14-2
14-2-1
MSW (Memory Switch) Specifications
The following describes memory switch specifications.
The symbols used in the Emulation cells below mean the following:
• SL: STAR Line Mode
• SP: STAR Page Mode
• EP: ESC/POS Mode
MSW 0
Bit Functions OFF/“0” ON/“1” Emulation Note
SL SP EP
F
E
D
C
B
A
9
8
7
6 Japanese Language Chinese
Characters
SHIFT-JIS Dedicated
Mode
SHIFT-JIS/JIS Mixed
Mode
- ○ - *4
5 SHIFT-JIS Kanji Mode Enabled Disabled ○ - - *2
4 Destination Specifications SBCS (Single Byte
Countries)
DBCS (Double Byte
Countries)
○ ○ ○ *3
3 (Reserved: Fixed at 0)
2 (Reserved: Fixed at 0)
1
0
*2) SHIFT-JIS Kanji Mode
Enabled when installed with Japanese language characters and DBCS settings.
See the table below for information relating to JIS kanji mode/SHIFT-JIS kanji mode when Japanese language kanji are
installed. (JIS Kanji mode is ignored with the power is turned on.)
<STAR Line Mode Japanese Language Characters Installed: SHIFT-JIS/JIS Specifications>
SHIFT-JIS Kanji Mode JIS Kanji Mode Print Mode
Disabled Disabled Japanese Kanji ANK Mode (MSW 0-5 = “1”)
Enabled Disabled SHIFT-JIS Kanji Mode (MSW 0-5 = “0”)
Disabled Enabled JIS Kanji Mode
Enabled Enabled JIS Kanji Mode
*3) Specifications for Destination
The settings affect the selection of the ANK code table in the STAR page mode. They select the Katakana mode only
when Japanese language characters are installed and went DBCS is set.
*4) Japanese Language Specifications
These settings are enabled only in STAR Page Mode and when Japanese language characters are installed.
When the SHIFT-JIS dedicated mode is selected, if the reception data is 0x20-0x7F, 0xA0-0xDF, the printer processes this
as a one byte code. If the reception data is 0x81-0x9F, 0xE0-0xEF, the printer processes it as two byte codes with the
subsequent data.
When the SHIFT-JIS/JIS mixed mode is selected, reception data is always processed as two byte codes.
TSP1000 Series Product Specifications 14-4
