e-STUDIO281c/351c/451c
1.5.3 Color Registration Control Procedure 2: To Correct Out-of-register colors
with Test Print Pattern 64 (05-64)
(1) Enter adjustment mode [05] and print out the test print pattern to correct out-of-register colors.
• Use steps (a) to (b) to print out the test print pattern.
(a) Select A3/LD-sized paper.
(b) Enter a code corresponding to a desired test print pattern. Press the [FAX] button.
• Print out any of the following test print patterns in the table below.
[05] code Test print pattern
Paper
size
No. of copies
to be printed
05-62 Grid pattern (for identifying out-of-register colors) A3/LD 2
05-64 Test print pattern 64 (block pattern) A3/LD 2
* Use code 05-62. The grid pattern will be printed on the entire copy, with all toner colors (C, M, Y
and K) overlaid. Check the printed grid pattern (or whether the toner colors are accurately
overlaid) to discover out-of-register colors on the entire copy.
* Jot down a "page number" and "paper feeding direction" on the printed test print pattern
beforehand. This facilitates identifying out-of-register colors in the subsequent adjustment.
(2) Enter adjustment mode [05]. Change the values for codes [417] and [418] to correct out-of-register colors.
• Align 3 toner colors (Y, C and K) with magenta (M). First, change the value for code 05-417 and correct
out-of-register colors on the first page of the test print pattern. Next, print out the 2 copies of test print
pattern again. Change the value for code 05-418 and correct out-of-register colors on the second page.
Color [05] code Subcode Value recommended Acceptable value range
Y (yellow) 3
M (magenta) 2
C (cyan) 1
K (black)
05-417
0
125 to 131 118 to 138
Y (yellow) 3
M (magenta) 2
C (cyan) 1
K (black)
05-418
0
125 to 131 118 to 138
* If the set value is increased by 1, the print position of the color will be shifted for 0.0423 mm toward the
trailing edge of the paper. (For instance, if the value for code 05-417-1 is increased by 3, the print position
of cyan will be shifted for 0.1269 mm (0.0423mm x 3) toward the trailing edge of the paper. This
correction will affect all pages.
