Error! Style not defined. Error! Style not defined. 4 Replacement Procedures
4.22 Bluetooth Card
rd
7.
Bluetooth card out.
3. Remove the card from the logic lower assembly.
Removing the Bluetooth ca
Remove the Bluetooth card according to the following procedures and Figure 4.4
1. Remove the Bluetooth cable from the Bluetooth card.
2. Press down the latch and push the Bluetooth card in the direction indicated in the figure
4.47 and slide the
Figure 4.47 Removing the Bluetooth card
NOTE: Be careful not to damage the Bluetooth Card when connecting it with the cable. Make
sure the card is seated in the correct position.
Satellite L500 Maintenance Manual 4-57
