3.2.1 IDE Channel 0/Secondary//Master/Slave Setup
Computer detects IDE drive type from drive C to drive F.
Press Enter on any of the Channel 0/Master, Channel 0/Slave,
Secondary/Master, Secondary/Slave options to view advanced details of the
corresponding drive. The system displays advanced details like the number of
heads/cylinders/sectors on the detected disk and the maximum storage
capacity of the disk.
PhoenixBIOS Setup Utility
Main Advanced Security Power Boot Exit
Item Specific Help
Type:
Multi-Sector Transfers:
LBA Mode Control:
32 Bit I/O:
Transfer Mode:
Ultra DMA Mode:
[Auto]
[Disabled]
[Disabled]
[Disabled]
[Standard]
[Disabled]
User = your enter
parameters of hard-disk
drive installed at this
connection.
Auto = autotypes hard-
disk drive installed here.
1-39 = you select pre-
determined type of
hard-disk drive installed
here.
CD-ROM = a CD-ROM
drive is installed here.
ATAPI Removable =
removable disk drive is
installed here.
F1 Help Select Item -/+ Change Values F9 Setup Defaults
Esc Exit Select Menu Enter Select
X Sub-Menu F10 Save and Exit
The system displays advanced details like the number of
heads/cylinders/sectors on the detected disk and the maximum storage
capacity of the disk.
This option lets you set the following hard disk parameters:
Type
Selects the type of device connected to the system.
Auto / User / Other ATAPI / IDE Removable / CD-ROM / ATAPI
Removable / None
Multi-Sector Transfers
This option allows you to specify the number of sectors per block for multiple
sector transfers.
16 Sectors / 2 Sectors / 4 Sectors / 8 Sectors /Disabled
LBA Mode Control
Enables or disables LBA Mode.
