3.5 Power
These settings allow you to configure the power options for your system.
PhoenixBIOS Setup Utility
Main Advanced Security Power Boot Exit
Item Specific Help
Resume On Time:
Resume Time:
Power On By PCI/PCI-X
Chassis Intrusion Detect:
After Power Failure:
[Off]
[xx:xx:xx]
[Disabled]
[No]
[Stay Off]
Enabled wakes the
system up at a specific
time.
F1 Help Select Item -/+ Change Values F9 Setup Defaults
Esc Exit Select Menu Enter Select
X Sub-Menu F10 Save and Exit
Resume On Time
When enabled, this allows the system to be worked up at a specified time. This
time is specified by the Resume Time parameter.
Off / On
Resume Time
This option allows the user to specify the time when the system is to wake up.
Power On By PCI/PCI-X
This option allows you to power on the system by PCI or PCI-X card. When
enabled, an input signal from PME on the PCI card awakens the system from a
S5 state.
Disabled / Enabled
Chassis Intrusion Detect
This feature is used to enable/disable the function: when chassis open event is
detected, BIOS will record the event.
No / Yes
After Power Failure
Specifies the mode of operation after the system recovers from a power loss.
Stay off / Last State / Power on
