Page 20 © 2002, ADTRAN, Inc. 64200600L1#T-31A
Total Access 600R User Interface Guide (UIG)
2. TERMINAL MENU AND SYSTEM CONTROL
Selecting the Appropriate Menu
The terminal menu is the access point to all other operations. Each terminal menu item has several functions and sub-
menus that identify and provide access to specific operations and parameters. Use the chart below to help select the
appropriate terminal menu.
Security Levels
To edit terminal menu items, you must have a password and the appropriate security level. Table 1 describes the secu-
rity levels.
To do this... Go to this menu...
Review and monitor general system information for the Total Access 600R
S
YSTEM
I
NFO
Set up the operational configuration for the Total Access 600R
S
YSTEM
C
ONFIG
Upgrade firmware, do config transfers, ping, and access terminal mode
S
YSTEM
U
TILITY
Define, configure, and monitor all Total Access 600R Router functions
R
OUTER
Review and configure settings for the network interface and configure the DS0
maps
M
ODULES
Table 1. Password Security Level
Security Level Description
5 Read-only permission for all menu items - minimum rights
4 Read permission for all menu items and permission to use test commands
3 Access to all commands except passwords, flash download, authentication methods,
interface configurations, and telnet security levels
2 Access to all commands except passwords, flash download, authentication methods, and
telnet security levels
1 Access to all commands except passwords and telnet security levels
0 Permission to edit every menu item, including creating and editing passwords - maximum
rights
Router Only Read access to all menus and write access to only the router menu
