SERVSWITCH™ BRAND CAT5 KVM MICRO EXTENDER
2. Specifications
Cable Required — Between Local and Remote Units: Category 5 solid
unshielded or shielded twisted pair (UTP or STP),
wired to the EIA/TIA-568A or (preferred) -568B
standard, terminated with RJ-45 male connectors; for
pinning/pairing, see the Appendix
Compliance — CE Class B; FCC Part 15 Subpart J Class A, IC Class/
classe A
Compatibility — Video: VGA, SVGA, XGA, XGA-2, or RGsB (sync on
green), although if your system has monitor ID-bit
requirements, you might need to call Black Box for
technical support;
Keyboard: IBM PC/AT or PS/2 compatible (PC/AT
types require connector adapter);
Mouse: IBM PS/2 compatible two-button, Microsoft
IntelliMouse, or Logitech PS/2 compatible 3-button
Interfaces — To monitor: VGA;
To keyboard and mouse: IBM PS/2 compatible;
To/from CPU and between Units:
Proprietary composites of the above
Resolution — Up to 1280 x 1024
Video I/O
Signal Levels — 0.7 Volts peak-to-peak
Video
Compensation — For short- or long-distance (user-switchable)
Synchronization — H/V or composite, TTL signal levels; sync polarity is
preserved
Video Coupling — DC
