SERVSWITCH™ BRAND CAT5 KVM MICRO EXTENDER
4. Checklist of System Components
4.1 The Complete Package
These items should be included with your ServSwitch™ Brand CAT5 KVM Micro
Extender package (please contact Black Box right away if any are missing or
damaged):
• (1) Micro Extender Local Unit.
• (1) Micro Extender Remote Unit.
• (1) 9-VDC 1-amp power-supply transformer and output cord.
• (1) Power-supply input cord suitable for your country or region.
• (1) 1-m (3.3-ft.) KVM-extension cable (runs from CPU to Local Unit) with a
DB25 male connector at the Unit end and an HD15 male connector and two
6-pin mini-DIN male connectors at the CPU end. (If your system uses 5-pin DIN
keyboard connectors, see the start of Section 4.2 for how you’ll connect it.)
• (1) Copy of this manual.
4.2 The Cables You’ll Need
If you are using the ServSwitch™ Brand CAT5 KVM Micro Extender to get greater
distance between a CPU and a VGA monitor, PS/2 keyboard, and PS/2 mouse,
your Micro Extender package should have included everything you’ll need except
for your Unit-interconnection cable. Read Sections 4.2.1, 4.2.3, and 4.2.5 carefully,
then skip ahead to Chapter 5.
If you are using the Micro Extender to get greater distance between a ServSwitch
family KVM switch and a CPU, a user station (monitor/keyboard/mouse), or a
compatible switch, you might need additional non-included cabling. Read the
relevant sections on the next few pages, from Section 4.2.1 through Section 4.2.5.
If you are using any equipment with PC/AT style connectors, you might also
need some combination of these adapters:
• To attach a CPU or KVM switch with a 5-pin DIN female keyboard
connector
to the Local Unit: A keyboard-port adapter such as product code FA211.
• To attach a CPU or KVM switch with an RS-232 serial DB9 male mouse connector
to the Local Unit
: A mouse-port adapter such as product code AC244A. (If the
mouse port is DB25 rather than DB9, you’ll also need an FA521A serial adapter
.)
•
To attach a keyboard or KVM switch with a 5-pin DIN male keyboard connector
to the Local or Remote Unit:
A keyboard adapter such as product code FA212.
