Chapter 1
6
MFC-6490CW Control panel overview 1
The MFC-5890CN and MFC-6490CW have the same control panel keys.
Note
Most of the illustrations in this User’s Guide show the MFC-6490CW.
1 Fax and telephone keys:
Fax Preview
Lets you preview incoming and outgoing
faxes on the LCD.
Hook
Press before dialing if you want to make
sure a fax machine will answer, and then
press Black Start or Color Start.
Also, press this key after picking up the
handset of an external telephone during the
F/T pseudo/double-ring.
Redial/Pause
Redials the last 30 numbers called. It also
inserts a pause when programming quick
dial numbers.
2Dial Pad
Use these keys to dial telephone and fax
numbers and as a keyboard for entering
information into the machine.
(Canada only) The # key lets you temporarily
switch the dialing mode during a telephone call
from Pulse to Tone.
3 Mode keys:
Fax
Lets you access Fax mode.
Scan
Lets you access Scan mode.
Copy
Lets you access Copy mode.
Photo Capture
Lets you access PhotoCapture Center
®
mode.
4 Menu keys:
Volume keys
d c
While the machine is idle, you can press
these keys to adjust the ring volume.
Phone Book key
Press to store One Touch, Speed Dial and
Group numbers in the machine’s memory.
Lets you store, look up, and dial numbers
that are stored in the memory.
21
910
Me
Mem.
Me
Fax
12:45
12.21.2009
