Chapter 21: RMON Configuration Guide
308 SmartSwitch Router User Reference Manual
• Samples taken at 300 second (5 minute) intervals.
• A “Startup” alarm generation condition instructing the SSR to generate an alarm if the
sample is greater than or equal to the rising threshold or less than or equal to the falling
threshold.
• Compare value at time of sampling (absolute value) to the specified thresholds.
• Rising and falling threshold values are 1.
• Rising and falling event index values are 15, which will trigger the previously-
configured Event.
Displaying RMON Information
The CLI rmon show commands allow you to display the same RMON statistics that can
be viewed from a management station. To display RMON statistics for the SSR, use the
following CLI command lines in Enable mode:
ssr#(config) rmon alarm index 20 variable 1.3.6.1.2.1.31.1.5.0 interval
300 startup both type absolute-value rising-threshold 1 falling-
threshold 1 rising-event-index 15 falling-event-index 15 owner "help
desk"
1
To show Ethernet statistics. rmon show etherstats <port-list>|all-ports
To show all events and logs. rmon show events
To show all alarms. rmon show alarms
To show histories and logs. rmon show history <port-list>|all-ports
To show hosts and logs. rmon show hosts <port-list>|all-ports [summary]
To show all Host Top N and
logs.
rmon show host-top-n
To show matrices and logs. rmon show matrix <port-list>|all-ports
To show all channels. rmon show channels
To show all filters. rmon show filters
To show all packet captures
and logs.
rmon show packet-capture
To display the RMON 2
Protocol Directory.
rmon show protocol-directory
To display the RMON 2
Protocol Distribution.
rmon show protocol-distribution <port-list>|all-
ports
