Chapter 22: WAN Configuration Guide
324 SmartSwitch Router User Reference Manual
Setting up a Frame Relay Service Profile
Once you have defined the type and location of your Frame Relay WAN interface(s), you
can configure your SSR to more efficiently utilize available bandwidth for Frame Relay
communications.
Note:
The SSR comes with a set of “default values” for Frame Relay interface
configuration settings, which means that setting up a Frame Relay service profile
is not absolutely necessary to begin sending and receiving Frame Relay traffic on
your SSR.
After you configure one or more service profiles for your Frame Relay interface(s), you
can then apply a service profile to active Frame Relay WAN ports, specifying their
behavior when handling Frame Relay traffic. The following command line displays all of
the possible attributes used to define a Frame Relay service profile:
Applying a Service Profile to an Active Frame Relay WAN Port
Once you have created one or more frame relay service profiles, you can specify their use
on one or more active frame relay WAN ports on the SSR. The following command line
displays a simplified example of this process:
Define a frame
relay service
profile.
frame-relay define service <service name> [Bc <number>]
[Be
<number>] [becn-adaptive-shaping <number>] [cir
<number>] [high-priority-queue-depth <number>] [low-
priority-queue-depth
<number>] [med-priority-queue-
depth
<number>] [red on|off] [red-maxTh-high-prio-
traffic
<number>] [red-maxTh-low-prio-traffic
<number>] [red-maxTh-med-prio-traffic <number>]
[red-minTh-high-prio-traffic
<number>] [red-minTh-
low-prio-traffic
<number>] [red-minTh-med-prio-
traffic
<number>] [rmon on|off]
Apply a service profile to
an active WAN port.
frame-relay apply service <service name> ports
<port list>
