Central Processing Unit: MPC860P Exception Handling
10002367-02 PmT1 and PmE1 User’s Manual
3-3
MPC860P EXCEPTION HANDLING
Each type of CPU exception transfers control to a different address in the vector table. The
vector table normally occupies the first 8-kilobytes of RAM (with a base address of
0000,0000
16
) or flash (with a base address of FFF0,0000
16
). An unassigned vector position
may be used to point to an error routine or for code or data storage.
Tab le 3 -4 lists the
exceptions recognized by the MPC860P in the order of their priority
Table 3-4: MPC860P Exceptions
FF00,0950 PADIR 000A Port A data direction register
FF00,0952 PAPAR 0000 Port A pin assignment register
FF00,0954 PADDR 0000 Port A open drain register
BRGs
FF00,09F0 BRGC1 10144 BRG1 configuration register
FF00,09F4 BRGC2 10144 BRG2 configuration register
SMCs
FF00,0A82 SMCMR1 4823 SMC1 mode register
FF00,0A92 SMCMR2 4823 SMC2 mode register
PIP
FF00,0AB8 PBDIR 0030 Port B data direction register
FF00,0ABC PBPAR 00C0 Port B pin assignment register
FF00,0AC2 PBODR 0010 Port B open drain register
SI
FF00,0AE0 SIMODE 1000,0000 SI mode register
FF00,0AEC SICR 0000,0000 SI clock route
Exception:
Vector Address
Hex Offset: Notes:
Development port NMI 01F00 Highest priority
NMI reset 00100
Tr ace 0 0D 00
Instruction TLB miss 01100
Instruction TLB error 01300
Machine check 00200
Instruction breakpoint 01D00
Software emulation 01000
Alignment 00600
System call 00C00
Data TLB miss 01200
Physical
Address (hex): Register:
Required
Hex Format: Description: (continued)
