System Management Console User Guide
Standard
3 In the Add Trusted Device dialog box, enter the configuration data:
• Name—Enter the name of the device, such as MAS110.
• DeviceAddress—Use the drop-down list to select the address of the
device.
4 Click Apply.
Deleting an external node
1 Select an entry on the External Nodes window.
2 Click Delete.
3 Click Yes to confirm the delete.
Informational elements
To configure this data you must have InfoElementService privileges.
Configuring an informational element
1 In the System Management Console, from the navigation pane, select
Network Data and Mtc > Informational Elements.
2 Click Add or select an entry and click Edit.
3 In the Add Informational Element (IE) dialog box, enter the configuration
data:
• ShortName: the name of the device, such as MAS110
• LongName: the long name of the device (same as the description of a
long name field for a Network Element)
• Node: external node configured
• Port: an integer, 0 to 65 534
• Trusted: specifies whether the informational element is trusted
The IE is trusted for SIP communications only, not for any other protocol.
• ExemptDoSProtection: specifies whether the IE is exempt from Denial
of Service Protection
• Type: Informational Element type
