XiNCOM X16-R Network Router User Manual



Page 60
SNMP
This section is only useful if you have SNMP (Simple Network Management Protocol) software on
your PC. If you have SNMP software, you can use a standard MIB II file with the MULTI-WAN
GATEWAY.
Figure 7-3: SNMP
Settings – SNMP
System
Information
Contact Person – The name of the person responsible for this device.
Device name – The name of this device.
Physical Location – The location of the device.
Community
Community Name – This is a password or key used between this device and
the management station. The administrator/manager must use the same
name when monitoring the device.
Access Control – Access privileges which allow the management station to
manage this device. This value may be: Read/Write, Read Only or No Access.
Trap Targets
Enter the IP addresses of any targets (PCs running SNMP software) to which you
want traps to be sent. All traps are level 1.
