<hour> integer from 0 to 23
<minute> integer from 0 to 59
<second> integer from 0 to 59
Example This example sets the real-time clock for 1 January 1992, 20:00:00 (8 PM).
OUTPUT XXX;":RTC 1,1,1992,20,0,0"
Query :RTC?
The RTC? query returns the real-time clock setting.
Returned Format
[:RTC] <day>,<month>,<year>,<hour>,<minute>,<second>
Example OUTPUT XXX;":RTC?"
SELect
Command :SELect <module>
The SELect command selects which module (or system) will have parser
control. SELect defaults to System (0) at power up. The appropriate module
(or system) must be selected before any module (or system) specific
commands can be sent. SELECT 0 selects the System, and SELECT 1 selects
the logic analyzer (state and timing). Select –2, –1 and, 2 through 10 are
accepted but no action will be taken. When a module is selected, the parser
recognizes the module’s commands and the System/Intermodule commands.
When SELECT 0 is used, only the System/Intermodule commands are
recognized by the parser. Figure 9-2 shows the command tree for the SELect
command.
<module> An integer 0 through 1 (–2, –1, and 2 through 10 unused).
Instrument Commands
SELect
9–19
