Query :MACHine{1|2}:TLISt:XPATtern? <label_name>
The XPATtern query returns the pattern specification for a given label name.
Returned Format
[:MACHine{1|2}:TLISt:XPATtern]
<label_name>,<label_pattern><NL>
Example OUTPUT XXX;":MACHINE1:TLIST:XPATTERN? ’A’"
XSEarch
Command :MACHine{1|2}:TLISt:XSEarch <occurrence>,<origin>
The XSEarch command defines the search criteria for the X marker, which is
then with associated XPATtern recognizer specification when moving the
markers on patterns. The origin parameter tells the marker to begin a search
with the trigger or with the start of data. The occurrence parameter
determines which occurrence of the XPATtern recognizer specification,
relative to the origin, the marker actually searches for. An occurrence of
0 (zero) places a marker on the selected origin.
<occurrence> integer from -1032192 to +1032192
<origin> {TRIGger|STARt}
Example OUTPUT XXX;":MACHINE1:TLIST:XSEARCH +10,TRIGGER"
Query :MACHine{1|2}:TLISt:XSEarch?
The XSEarch query returns the search criteria for the X marker.
Returned Format
[:MACHine{1|2}:TLISt:XSEarch] <occurrence>,<origin><NL>
Example OUTPUT XXX;":MACHINE1:TLIST:XSEARCH?"
TLISt Subsystem
XSEarch
24–20
