Example OUTPUT XXX;":MACHINE2:COMPARE:CMASK ’DATA’?"
COPY
Command :MACHine{1|2}:COMPare:COPY
The COPY command copies the current acquired State Listing for the
specified machine into the Compare Listing template. It does not affect the
compare range or channel mask settings.
Example OUTPUT XXX;":MACHINE2:COMPARE:COPY"
DATA
Command :MACHine{1|2}:COMPare:DATA
{<label_name>,<line_num>,<data_pattern>|
<line_num>,<data_pattern>[, <data_pattern>]... }
The DATA command allows you to edit the compare listing image for a given
label and state row. When DATA is sent to an instrument where no compare
image is defined (such as at power-up) all other data in the image is set to
don’t cares.
Not specifying the <label_name> parameter allows you to write data patterns
to more than one label for the given line number. The first pattern is placed
in the leftmost label, with the following patterns being placed in a left-to-right
fashion (as seen on the Compare display). Specifying more patterns than
there are labels simply results in the extra patterns being ignored.
Because don’t cares (Xs) are allowed in the data pattern, it must always be
expressed as a string. You may still use different bases but "don’t cares"
cannot be used in a decimal number.
