Example The following example would be used to specify this complex qualifier.
OUTPUT XXX;":MACHINE1:STRIGGER:BRANCH1 ’((A OR B) AND (F OR
G))’, 2"
Terms A through E, RANGE 1, and TIMER 1 must be grouped together
and terms F through J, RANGE 2, and TIMER 2 must be grouped together.
In the first level, terms from one group may not be mixed with terms from the
other. For example, the expression ((A OR IN_RANGE2) AND (C OR
G)) is not allowed because the term C cannot be specified in the F through
J group.
In the first level, the operators you can use are AND, NAND, OR, NOR,
XOR, NXOR. Either AND or OR may be used at the second level to join the
two groups together. It is acceptable for a group to consist of a single term.
Thus, an expression like (B AND G) is legal, since the two operands are both
simple terms from separate groups.
CLEar
Command :MACHine{1|2}:STRigger:CLEar
{All|SEQuence|RESource}
The CLEar command allows you to clear only the Sequence levels, clear only
the resource term patterns, or clear all settings in the State Trigger menu and
replace them with the default.
Example OUTPUT XXX;":MACHINE1:STRIGGER:CLEAR RESOURCE"
STRigger (STRace) Subsystem
CLEar
16–12
