Transferring the Logic Analyzer Configuration
This program uses the SYSTem:SETup? query to transfer the logic analyzer
configuration to your controller. This program also uses the SYSTem:SETup
command to transfer a logic analyzer configuration from the controller back
to the logic analyzer. The SYSTem:SETup command differs from the
SYSTem:DATA command because it only transfers the configuration and not
the acquired data.
10 ! ****************** SETUP COMMAND AND QUERY EXAMPLE ********************
20 ! for the Agilent 1670G-series
30 !
40 ! **************** INITIALIZE GPIB DEFAULT ADDRESS *********************
50 !
60 REAL Address
70 Address=707
80 ASSIGN @Comm TO Address
90 !
100 CLEAR SCREEN
110 !
120 ! ************* INTITIALIZE VARIABLE FOR NUMBER OF BYTES ***************
130 ! The variable "Numbytes" contains the number of bytes in the buffer.
140 !
150 REAL Numbytes
160 Numbytes=0
170 !
180 ! *********************** SEND THE SETUP QUERY **************************
190 OUTPUT @Comm;":SYSTEM:HEADER ON"
200 OUTPUT @Comm;":SYSTEM:LONGFORM ON"
210 OUTPUT @Comm;":SELECT 1"
220 OUTPUT @Comm;":SYSTEM:SETUP?"
230 !
240 ! ******************** ENTER THE BLOCK SETUP HEADER *********************
250 ! Enter the block setup header in the proper format.
260 !
270 ENTER @Comm USING "#,15A";Header$
280 PRINT Header$;
290 ENTER @Comm USING "#,A";Always_8$
300 PRINT Always_8$;
310 ENTER @Comm USING "#,8A";Numbytes$
320 PRINT Numbytes$
330 Numbytes=VAL(Numbytes$)
