Appendix C: Technical specifications
Axis NPS 550 User’s Manual 81
NetWare features
Standard installation using PCONSOLE
Print Server Mode for high-speed printing
Remote Printer Mode for up to 16 printers per NetWare user licence
Up to 96 print queues on 16 file servers
Port Status monitoring
Windows features
Automatic installation software (Axis Print Utility for Windows)
Printing through Windows Print Manager
Both peer-to-peer and client-server printing
OS/2 features
Automatic installation software (Axis Print Utility for OS/2)
Printing through OS/2 Print Manager
Port Status monitoring
Unix features
SNMP support: Axis private enterprise MIB and MIB-II
Macintosh features
Standard installation using the Chooser
Supports binary mode
Printer attachments
Two parallel Centronics ports (25 pin DSUB, throughput exceeding 250 kbytes/s, burst 1000 kbytes/s)
One serial RS-232C port (9 pin DSUB, XON/XOFF or RTS/CTS, transfer rates up to 115,200 baud)
Hardware specifications
Size: 7.7 × 1.3 × 5.2 inches / 195 × 32 × 133 mm
Weight: 1.8 lb / 0.8 kg
Power: 12-15 VDC or VAC, min 500 mA by external power supply
Approvals
EMC: Limit A of FCC Rules and Regulations part 15 subpart B, class A (US).
Limit B of EN 55022/1987, EN 50082-1/1992 (Europe).
Safety: EN 60950, UL
Operating environments
Temperature: 40 - 105 °F / 5 - 40 °C
Humidity: 10 - 95% non-condensing
All specifications are subject to change without prior notice
