Configuring your machine for a wireless network
33
3
f If the LCD shows Connected, the machine has successfully connected to your router or access point.
You can now use your machine in a wireless network.
If the LCD shows Incorrect Mode, session overlap is detected. The machine has detected more than
one router or access point on your network with the Wi-Fi Protected Setup™ mode or AOSS™ mode
enabled. Make sure that only one router or access point has the Wi-Fi Protected Setup™ mode or the
AOSS™ mode enabled and try starting from c again.
If the LCD shows Connection NG (or Connection error), the machine has not successfully
connected to your router or access point. Try starting from c again. If the same message is indicated
again, reset the machine back to the default factory settings and try again. For resetting, see Restoring
the network settings to factory default on page 87.
If Connection NG (or Connection error) is shown after Setting WLAN, this may be due to a
session overlap detection error. The machine has detected more than one router or access point on your
network with the SecureEasySetup™ mode, Wi-Fi Protected Setup™ mode or AOSS™ mode enabled.
Make sure that only one router or access point has the SecureEasySetup™ mode,
Wi-Fi Protected Setup™ mode or AOSS™ mode enabled and try starting from c again.
(For Windows
®
)
You have completed the wireless network setup. If you would like to continue installing drivers and
software necessary for operating your device, please choose Install MFL-Pro Suite from CD-ROM
menu.
LCD messages when using the SES/WPS/AOSS control panel menu
LCD shows Connection status Action
Setting WLAN
Searching or accessing the access
point, and downloading settings from the
access point
—
Connecting SES
Connecting WPS
Connecting AOSS
Connecting the access point —
Connected Connection succeeded. —
Incorrect Mode Session overlap is detected.
Check that only one router or access point has
the Wi-Fi Protected Setup™ mode or AOSS™
mode enabled and try starting from c again.
Connection NG
Connection error
Connection failed. 1 Try starting c again.
2 If the same message continues, reset the
machine back to the factory settings and try
again.
(If it is shown after
the LCD shows
Setting WLAN.)
Connection failed.
Session overlap is
detected.
Check that only one router or access point has
the SecureEasySetup™ mode, Wi-Fi Protected
Setup™ mode or AOSS™ mode enabled and try
starting from c again.
