Chapter 2 Setting Up 2-19
Setting Up
Loading Paper in the Multi-Purpose Tray
Follow this procedure to load paper in the multi-purpose tray:
1 Make sure the paper thickness lever is
set to p (up).
• For details, 1 p. 5-6.
c
Do not set the paper thickness lever
while the unit is printing since this
will cause problems.
2 Raise the paper rest until it stops q,
then move the paper guide to the left to
match the size of your paper w.
3 Prepare a stack of paper by fanning
the edge that will feed into the unit first,
and then by tapping the stack on a flat
surface to even its edges.
4 Insert the stack into the multi-purpose
tray q, and align the right edge of the
stack with the right side of the multi-
purpose tray. Slide the paper guide
snugly against the left edge of the
stack w.
• The multi-purpose tray holds up to 100
sheets of 75 g/m
2
plain paper.
• Make sure the stack does not exceed the
paper limit mark (P).
The MultiPASS is now ready to print.
2
1
PAPER LIMIT MARK
2
1
