iDP3310 User's Manual
34 CITIZEN
10. PRINT CONTROL FUNCTIONS
10.1 Commands List
P-250 iDP-562
Command Function Code
P-200 P-250 40 ch 42 ch
Refer to
LF Line Feed 0AH 37
CR Print 0DH
××
37
FF Eject Paper 0CH 38
CAN
Clear Print Buffer
Cancel Character Attribute
18H
38
NULL Pad Character(NOP) 00H 39
DC2 Specify Underline 12H 39
DC3 Specify the Repeat Print 13H 39
FS Execute P-250 Mode 1CH
× ×
40
GS Execute P-200 Mode 1DH
×
×
40
RS Set Double Width Character 1EH 41
US Set Normal Width Character 1FH 41
SO Set Double Width Character
or specify High Page
0EH 42
SI Set Normal Width Character
or Reset Character code
0FH 42
BELL Drawer Kick-out(D-type only) 07H 43
ESC a(n); Set Line Height 1BH61H(n)3BH 43
ESC b(n); Eject Paper by n lines 1BH62H(n)3BH 44
ESC c Initialize 1BH63H 44
ESC d Request Printer Status 1BH64H
×
×
45
ESC e(n); Set Right Margin 1BH65H(n)3BH
×
××
45
ESC f(n); Set Line Attribute 1BH66H(n)3BH 46
ESC g Graphic Mode Activate 1BH67H
×××× −
ESC h(n); Select Character Set 1BH68H(n)3BH 46
ESC i Identify Printer 1BH69H
×
××
47
ESC x Select P-900R Mode 1BH78H 47
ESC C n Set Page Length and Paging 1BH43H n
××
48
ESC O Cancel Paging 1BH4FH
××
48
ESC
* m nn
Specify Bit Image Mode 1BH2AH m n 49
ESC Y Specify the Repeat Print 1BH59H 50
* P-250 represents both P-250 and P-900R modes.
P-250 mode basically equals to P-900R except the printer ID and some status sent to the host from the printer.
Refer to the attached “Commands Details”.
* P-200 represents the P-200 mode.
* 40ch and 42ch represents useable columns for iDP-562.
* (n) in the command indicates the character code 30h to 39h.
*
: Command enable,
×
: Command disable
* n m in the code indicates the character codes 00h to FFh.
