G-Series Touchpanel Interface: TPS-GA-TPI Operations Guide – DOC. 6501
Video Setup Details
VIDEO SETUP
SCREEN
CONTROLS
DESCRIPTION
Setup Video 1
Displays the VIDEO 1 SETUP menu. By default, the VIDEO
1 SETUP menu displays video controls: Brightness,
Contrast, Saturation and Hue on the right side of the menu.
Video
Pressing this before pressing the Setup Video 1 button will
open the VIDEO 1 SETUP menu in Video mode.
S-Video
Pressing this before pressing the Setup Video 1 button will
open the VIDEO 1 SETUP menu in S-Video mode.
Component
Pressing this before pressing the Setup Video 1 button will
open the VIDEO 1 SETUP menu in Component mode.
RGB
Pressing this before pressing the Setup Video 1 button will
open the VIDEO 1 SETUP menu in RGB mode.
Setup Video 2
Displays the VIDEO 2 SETUP menu. By default, the VIDEO
2 SETUP menu displays video controls: Brightness,
Contrast, Saturation and Hue on the right side of the menu.
Video
Pressing this before pressing the Setup Video 2 button will
open the VIDEO 2 SETUP menu in Video mode.
S-Video
Pressing this before pressing the Setup Video 2 button will
open the VIDEO 2 SETUP menu in S-Video mode.
Component
Pressing this before pressing the Setup Video 2 button will
open the VIDEO 2 SETUP menu in Component mode.
RGB
Pressing this before pressing the Setup Video 2 button will
open the VIDEO 2 SETUP menu in RGB mode.
The following screen is displayed when Video, S-Video or Component are selected.
VIDEO 1 SETUP (Video, S-Video and Component)
