42 • Isys
®
G-Series Touchpanel Interface: TPS-GA-TPI Operations Guide – DOC. 6501
TCP/IP Communication
NOTE: Required for operation with a Crestron control system.
Ethernet Communication
PC RUNNING
ETHERNET
CRESTRON TOOLBOX
TPS-GA-TPI
• Establish serial communication between TPS-GA-TPI and PC.
• Enter the IP address, IP mask and default router of the TPS-GA-TPI via the
Crestron Toolbox (Functions | Ethernet Addressing); otherwise enable
DHCP.
• Confirm Ethernet connections between TPS-GA-TPI and PC. If connecting
through a hub or router, use CAT5 straight through cables with 8-pin RJ-45
connectors. Alternatively, use a CAT5 crossover cable to connect the two
LAN ports directly without using a hub or router.
• Use the Address Book in the Crestron Toolbox to create an entry for the
TPS-GA-TPI with the TPS-GA-TPI’s TCP/IP communication parameters.
• Display the “System Info” window (click the
icon) and select the
TPS-GA-TPI entry.
Programs, Projects and Firmware
Program, project or firmware files may be distributed from programmers to installers
or from Crestron to dealers. Firmware upgrades are available from the Crestron
website as new features are developed after product releases. One has the option to
upload programs and projects via the programming software or to upload and
upgrade via the Crestron Toolbox. For details on uploading and upgrading, refer to
the SIMPL Windows help file, VisionTools Pro-e help file, or the Crestron Toolbox
help file.
SIMPL Windows
If a SIMPL Windows program is provided, it can be uploaded to the control system
using Simple Windows or Crestron Toolbox.
VisionTools Pro-e
Upload the VisionTools Pro-e file to the touchpanel interface using VisionTools
Pro-e or Crestron Toolbox. If loading a project to a touchpanel interface that has an
external compact flash slot, please use Crestron Toolbox.
Firmware
Check the Crestron website to find the latest firmware. (New users may be required
to register to obtain access to certain areas of the site, including the FTP site.)
Upgrade TPS-GA-TPI firmware via Crestron Toolbox.
• Establish serial or TCP/IP communications with the TPS-GA-TPI and
display the “System Info” window.
• Select Functions | Firmware… to upgrade the TPS-GA-TPI firmware.
