3 Name and Functions of Each Part
Name of Each Part
The following describes name and functions of each part:
Fig. 3.1.1 Name of Each Surface Mounted Part (with LCD Panel)
(1)
Power LED (Blue) (7) LED (13) Key switch
(2)
Speaker (Left) (8) POWER SW (14) Crystal oscillator (48MHz/32KHz)
(3) RESET SW (9)
GND pin (15) S1C17801
(4)
USBminiB connector (10)Speaker (Right) (16) LCD board
(5)
LED (RGB) (11) JP pin
(6)
MIC (12)Expansion connector
(2)
(1)
(3)
(4)
(5)
(6) (7)
(8)
(9)
(13)(15)
3.5inch
STN QVGA B&W
Membrane touch panel
(14) (9)(16)(9)
CPU board ICD board
(10)
(5)
(11)
(12)
