Chapter 2: Magnum Router Features
___________________________________________________________________
Magnum Router Specifications
Standard Compliance
Microprocessor
Motorola MPC-860T, 50Mhz T1.617 ANNEX-D, ITU Q933-ANNEXA
ITU I.233, ANSI T1.606
Memory
ITU Q922-ANNEXA, ANSI T1.618
64 MB SDRAM, 2MB FLASH, 16MB FLASH
DISK-ON-CHIP
Management Options
Windows based PC with GUI interface.
Interface Connections
One male DB 25 V.35 (M1), Three male
DB25 V.35 WAN ports, One female DB25
RS-232 console port, One RJ 45 10/100
Base T Ethernet port.
Models
M5000M/R1, Magnum Router Module
M5000M/SR1, Magnum Router Standalone
Version
LAN Connection
Ethernet: auto-sensing 10/100 Base-T UTP.
Cables (included)
M5000C/CAT5E, Ethernet port cable.
WAN Connection
M5000C/CP, console port cable.
3 T1/E1 WAN ports support data rates from
56Kbps to 2.048 Mbps
M5000C/MODEM, Magnum Console to
Modem Cable
IP Routing
M5000C/MATRIX, Magnum Console to
Marathon Async Cable
Incorporates industry standard IP routing
Performance
Forwarding Rate: 4000 packets per second.
Agency Compliance
Aggregate Sustained Throughput: 20 Mbps
ISO 9000 Certified
Frame Relay Support
Storage Temperature
DLCI’s/PVC’s: Unlimited
55 to +85 C
Frame Size: 2K
Operating Temperature
0 to +50 C
Compatibility
The Magnum Router is compatible with
other manufacturers RFC 1490 compliant
products.
Operating Humidity
Up to 95% non-condensing
Must reside in a new or existing Marathon
Base Unit Chassis: 2K, 2K+, 3K, NR75E,
5Kturbo, 5KTPro, 10K, 20K, 20Kpro. All
Marathon units must be software revision
5.0 or greater.
Operating Air Pressure
10,000 feet (3050 m) maximum altitude
2-2
